1823 Dingli Scissor lift specification
The Dingli 1823 Hybrid is a powerful, flexible scissor lift designed for contractors who need indoor efficiency and outdoor capability in one machine. Its hybrid power system allows quiet, zero-emission electric operation indoors, with the option of engine power when working outside or over longer shifts. It drives at full height, improving productivity by reducing the need to lower and reposition the platform, and features a secondary guard system for added operator safety. With a high working height, strong platform capacity, and excellent drive performance, it’s well suited to steelwork, cladding, maintenance, and installation jobs. Built by Dingli, the 1823 Hybrid delivers reliable performance, reduced downtime, and the versatility modern sites demand.
Genie 1823 Specifications
Work height: 59 ft 1 in / 18.00 m
Platform height: 52 ft 6 in / 16.00 m
Safe working load: 680 kg (1,499 lb)
Overall length (with outriggers): 16 ft / 4.88 m
Overall width: 7 ft 8 in / 2.33 m
Overall height (rails up): ~10 ft 7 in / 3.23 m
Platform size (L × W): 16 ft × 6 ft / 4.88 m × 1.83 m
Platform extension (dual deck): 4 ft 8 in / 1.43 m and 3 ft 8 in / 1.13 m
Ground clearance: ~1 ft / 0.30 m
Wheelbase: ~9 ft 5 in / 2.86 m
Gradeability: 40 %
Travel speed (stowed): ~6 km/h; travel speed raised: ~1.1 km/h
Drive: 4-wheel drive & 2-wheel steering
Drivable at full height: Yes
Power: Hybrid (Diesel + Electric assist)
Operating weight: ~8,840 kg / 19,489 lb
Secondary guard system: Yes (standard safety features)
